PUMP BODY:
cast iron, with UIN ISO 228/1 gas threaded suction and delivery openings,
threaded side openings for installing a pressure gauge and pressure switch.
PUMP BODY COVER: cast iron,serving also as mechanical seal horsing.
EJECTOR UNION: plastic PPO (approved for drinking water)
IMPELLER: brass, centrifugal radial flow
MOTOR SHAFT: AISI 314 stainless steel,
MECHANICAL SEAL: ceramic and graphite,
MOTOR:
the pumps are coupled to an asynchronous, high efficiency TEK induction
motor of suitable size, which is quiet, closed and externally ventilated,
suitable for continuous duty. INSULATION class B (Class F)
The thermal cutout replay (motor protector ) is incorporated in all single
phase motors.
Three phase motors require an adequate external motor protector, with
connections according to current standards.
PROTCTION: IP 44.
OPERATING LIMITS:Fluid temperature up to+40℃
Maximum ambient temperature+40℃



Model	Power		Q.Max	H.Max	S.Max	Pipe Dia.	Packing Dim.	G.W	Qty/20ft	R.P.M	Ampere
	KW	HP	L/min	m	m	mm	mm	kg	pcs		1~220V	3~380V
JSP-100	0.33	0.45	40	35	9	25x25	410x170x180	10.2	1320	2850	2.7	-
JSP-255	0.37	0.5	45	38	9	25x25	410x170x180	14	1320	2850	3	-
JSP-355	0.55	0.75	50	45	9	25x25	460x210x230	15.1	1320	2850	3.6	-
JSP-455	0.75	1	60	48	9	25x25	460x210x230	16	800	2850	4.8	-
JSP-555	1.1	1.5	80	56	9	32x32	590x218x258	26	800	2850	7.5	2.7
JSP-655	1.5	2	100	60	9	40x40	590x218x258	27.5	800	2850	9.6	3.5
JSP-755	2.2	3	130	65	9	40x40	590x228x258	29	800	2850	13.5	5
