MOTOR:
the pumps are coupled to an asynchronous, high efficiency TEK induction
motor of suitable size, which is quiet, closed and externally ventilated,
suitable for continuous duty. INSULATION class B (Class F)
The thermal cutout replay (motor protector ) is incorporated in all single
phase motors.
Three phase motors require an adequate external motor protector, with
connections according to current standards.
protection: IP 44



Model	Power		Q.Max	H.Max	S.Max	Pipe Dia.	Packing Dim.	G.W	Qty/20ft
	KW	HP	L/min	m	m	mm	mm	kg	pcs
JSW-40	0.45	0.6	40	38	9	25x25	420x180x210	12.3	1500
JSW-45	0.6	0.75	50	42	9	25x25	420x180x210	13.2	1500
JSW-55/JSW-10M	0.75	1	60	45	9	25x25	490x210x220	16.6	1350
JSW-60/JSW-12M	0.9	1.2	70	50	9	25x25	490x210x220	16.9	1350
JSW-65/JSW-15M	1.1	1.5	80	60	9	32x25	590x210x260	21.6	960
JSW-75	1.5	2	90	70	9	40x25	590x210x260	23.5	960
